74HC595 Serial to Parallel Shifting IC

Description

The 74HC595 Serial to Parallel Shifting IC is a high-grade, precision-tested electronic component designed for reliable performance in prototyping, education, industrial control, and custom hardware engineering.

🔹 Key Features

• •[Logic Gates IC] DESCRIPTION:- The 74HC595N is a simple 8-bit shift register IC
• •Essentially it takes 8 bits from the serial input and then outputs them to 8 pins
• •This small DIP packaged IC contains an 8-bit, serial-in-parallel-out shift register that feeds an 8-bit D-type storage register with parallel 3-state outputs
• •Pin Configuration:- Pin Number Pin Name Description 1,2,3,4,5,6,7 Output Pins (Q1 to Q7) The 74hc595 has 8 output pins out of which 7 are these pins
• •It is active high 13 (OE) Output Enable The Output Enable is used to turn off the outputs
• •16 Vcc This pin powers the IC, typically +5V is used

🔹 Technical Specifications

🔹 Pin Configuration & Wiring

🔹 Applications

This component is engineered and suitable for:

• •Microcontroller interfacing (Arduino, ESP32, Raspberry Pi, STM32)
• •IoT telemetry, environmental monitoring, and smart home systems
• •Robotics navigation, obstacle detection, and motion sensing
• •STEM education, university electronics labs, and maker prototyping

🔹 Package Includes

• ✓1 × 74HC595 Serial to Parallel Shifting IC
