MAX30102 Pulse Oximeter Heart Rate Sensor Module
- •Product Name: MAX30102 Pulse Oximeter Heart Rate Sensor Module
- •Product Category: Sensors
- •Operating Voltage: 3.3V - 5V DC
- •Operating Temperature: -20°C to +65°C
- •Mounting Type: Through Hole / Screw Terminal / Modular
- •Efficiency / Accuracy: Up to 95%
- •[Proximity Sensor] MAX30102 is a sensor that combines a pulse oximeter and a heart rate monitor
- •This particular LED colour combination is designed to allow data to be read with the tip of one’s finger
Description
[Proximity Sensor] MAX30102 is a sensor that combines a pulse oximeter and a heart rate monitor. It’s an optical sensor that measures the absorbance of pulsating blood through a photodetector after emitting two wavelengths of light from two LEDs – a red and an infrared one. This particular LED colour combination is designed to allow data to be read with the tip of one’s finger. It is fully configurable through software registers and the digital output data is stored in a 16-deep FIFO within the device. It has an I2C digital interface to communicate with a host microcontroller. The pulse oximetry subsystem in MAX30102 consists of ambient light cancellation (ALC), 16-bit sigma-delta ADC, and a proprietary discrete-time filter. It has an ultra-low-power operation which makes it ideal for battery-operated systems. MAX30100 operates on a supply in the range of 1.8 to 3.3V. It can be used in wearable devices, fitness assistant devices, medical monitoring devices, etc. This sensor works on 3.3V Devices directly. You can connect it to 3.3V devices like ESP8266, ESP32, etc. directly. To use it with the Arduino UNO, Mega, Nano, etc. use a level shifter in between. Else I2C connection will not work. Features Heart-Rate Monitor and Pulse Oximeter Sensor in LED Reflective Solution Tiny 5.6mm x 3.3mm x 1.55mm 14-Pin Optical Module Integrated Cover Glass for Optimal, Robust Performance Ultra-Low Power Operation for Mobile Devices Programmable Sample Rate and LED Current for Power Savings Low-Power Heart-Rate Monitor (< 1mW) Ultra-Low Shutdown Current (0.7µA) Fast Data Output Capability High Sample Rates Robust Motion Artifact Resilience High SNR -40°C to +85°C Operating Temperature Range
🔹 Key Features
- •[Proximity Sensor] MAX30102 is a sensor that combines a pulse oximeter and a heart rate monitor
- •This particular LED colour combination is designed to allow data to be read with the tip of one’s finger
- •It is fully configurable through software registers and the digital output data is stored in a 16-deep FIFO within the device
- •It has an I2C digital interface to communicate with a host microcontroller
- •The pulse oximetry subsystem in MAX30102 consists of ambient light cancellation (ALC), 16-bit sigma-delta ADC, and a proprietary discrete-time filter
- •It has an ultra-low-power operation which makes it ideal for battery-operated systems
🔹 Technical Specifications
🔹 Pin Configuration & Wiring
🔹 Applications
This component is engineered and suitable for:
- •Microcontroller interfacing (Arduino, ESP32, Raspberry Pi, STM32)
- •IoT telemetry, environmental monitoring, and smart home systems
- •Robotics navigation, obstacle detection, and motion sensing
- •STEM education, university electronics labs, and maker prototyping
🔹 Package Includes
- ✓1 × MAX30102 Pulse Oximeter Heart Rate Sensor Module
