12V PCB Mount Sugar Cube SPDT Relay – 5 Pin 7A
—
₹17.00
₹15.00
(Inc. GST)Save 12%- •Product Name: 12V PCB Mount Sugar Cube SPDT Relay – 5 Pin 7A
- •Product Category: Power & Components
- •Operating Voltage: 12V DC
- •Max Current: 7A
- •Operating Temperature: -20°C to +65°C
- •Mounting Type: Through Hole / Screw Terminal / Modular
- •Despite its small size, this relay can be used to control loads up to 7A at 250V AC according to the provided specifications
- •The relay operates with a 12V DC coil and has a coil resistance of approximately 270Ω, with a nominal coil current of around 45mA
In stock(10 units ready to dispatch)
1
Check Delivery Availability of Your Pincode:
10 People watching this product right now!
Description
The 12V PCB Mount Sugar Cube SPDT Relay – 5 Pin 7A is a high-grade, precision-tested electronic component designed for reliable performance in prototyping, education, industrial control, and custom hardware engineering.
🔹 Key Features
- •Despite its small size, this relay can be used to control loads up to 7A at 250V AC according to the provided specifications
- •The relay operates with a 12V DC coil and has a coil resistance of approximately 270Ω, with a nominal coil current of around 45mA
- •The relay features 5 pins: two coil terminals, COM (Common), NO (Normally Open), and NC (Normally Closed)
- •The COM terminal is switched between NO and NC when the relay coil is energized or de-energized
- •When the 12V DC coil is energized, the internal contact switches from NC to NO
- •🛠️ How It Works Connect the relay coil terminals to a suitable 12V DC control supply
🔹 Technical Specifications
Product Name:12V PCB Mount Sugar Cube SPDT Relay – 5 Pin 7A
Product Category:Power & Components
Operating Voltage:12V DC
Max Current:7A
Operating Temperature:-20°C to +65°C
Mounting Type:Through Hole / Screw Terminal / Modular
Efficiency / Accuracy:Up to 95%
🔹 Pin Configuration & Wiring
🔹 Applications
This component is engineered and suitable for:
- •Microcontroller interfacing (Arduino, ESP32, Raspberry Pi, STM32)
- •IoT telemetry, environmental monitoring, and smart home systems
- •Robotics navigation, obstacle detection, and motion sensing
- •STEM education, university electronics labs, and maker prototyping
🔹 Package Includes
- ✓⚠️ Precautions Use a 12V DC supply for the relay coil. Do not exceed the specified contact voltage and current ratings. Ensure correct identification of COM, NO, NC, and coil terminals before wiring. Use suitable protection circuitry when driving the relay coil from sensitive electronic circuits. For inductive loads such as motors and solenoids, use appropriate suppression/protection components. Ensure proper PCB insulation and clearance when switching mains voltage. Disconnect power before changing or modifying wiring. Do not touch exposed mains-voltage terminals during operation. ally Open) then the load remains OFF before trigger. These relays are usually used in home automation, switching circuits, securi
