All products · 8 of 1440
Electronics, sensors, robotics kits, PC components, peripherals — everything Unik Systems carries, in one place.
LDR (Light Dependent Resistor)
Resistance varies with light: ~1–10kΩ bright, 100kΩ–1MΩ dark. Use in voltage divider with 10kΩ. Output: analog voltage to ADC.
Potentiometer 10k / 100k
Rotary/trim pot. Values: 10kΩ / 100kΩ. 3 pins (end A, wiper, end B). Variable voltage divider for ADC. Linear taper 'B'.
100K Rotary Potentiometer Round Shaft Elcon
[Potentiometer] 100KΩ Rotary Potentiometer Round Shaft Elcon The 100KΩ Rotary Potentiometer Round Shaft Elcon is a reliable 3-pin linear rotary potentiometer designed for adjusting electrical parameters such as voltage, current, brightness, motor speed, and other control functions in electronic circuits. By rotating the shaft, the resistance can be smoothly adjusted across its available range, making it suitable for a wide variety of DIY and electronic applications. With its compact 16mm body, 6mm round shaft, and through-hole mounting design, this potentiometer is easy to install on electronic PCBs and control panels. Its linear resistance characteristics make it suitable for applications such as LED brightness control, fan speed control, motor control, power supply adjustment, and general-purpose voltage control. ⭐ Key Features 100KΩ resistance value 3-pin rotary potentiometer Linear potentiometer Smooth rotary adjustment 6mm round shaft 13mm shaft length Compact 16mm body diameter Through-hole mounting Suitable for PCB and electronic circuits Ideal for voltage and resistance adjustment Suitable for DIY and electronic projects Elcon brand 📋 Technical Specifications Product Type: Rotary Potentiometer Brand: Elcon Resistance Value: 100KΩ Configuration: 3 Pin / Single Gang Tolerance: ±20% Shaft Type: Round Shaft Shaft Diameter: 6mm Shaft Length: 13mm Body Diameter / Width: 16mm Total Height: Approx. 28mm Mounting Type: Through Hole Operating Temperature: -40°C to +80°C Weight: Approx. 8g 🔧 Applications LED Brightness Control Fan Speed Control Motor Speed Control Voltage Adjustment Current Adjustment Power Supply Circuits Audio & Electronic Circuits Arduino Projects DIY Electronics Projects Electronic Prototyping 🛠️ How It Works A potentiometer is a variable resistor with three terminals. The two outer terminals are connected to the resistive track, while the center terminal acts as the wiper. Rotating the shaft changes the wiper position and therefore changes the resistance or output voltage in the circuit. 📦 Package Includes 1 × 100KΩ Rotary Potentiometer Round Shaft Elcon ⚠️ Note Product images are shown for illustrative purposes only and may differ slightly from the actual product. The 100KΩ value, tolerance, dimensions, and shaft length should be verified against the actual product batch before installation.
Out of stockTPA3116D2 50Wx2+100W Original IC 2.1 Channel Digital Subwoofer Amplifier Board 12V-24V
[Amplifier Board] This is TPA3116D2 IC 50Wx2+100W 2.1 Channel Amplifier Board 12V-24V. DC12-24V TPA3116D2 2.1 Channel Digital Subwoofer Power Amplifier Board adopts two high-quality TPA3116D2 digital amplifier chips. Sound quality is very good, high efficiency and amplifying power. 50W x 2+100W 2.1 channels (left/right channel and subwoofer channel), high efficiency and low-heat. Users can adjust the volume by themselves easily. It is powered by DC 12-24V, wide input voltage. You can check our others amplifier boards here. Features: Adopts two high-quality TPA3116D2 digital amplifier chips. Good sound quality, high efficient device and power amplifying feature. 50W x 2+100W 2.1 channels(left/right channel and subwoofer channel), high efficiency and low-heat. Powered by DC 12-24V, wide input voltage. User can adjust the volume by themselves easily. Applicable speaker impedance: 4-8 ohm. Just connect the power supply and loudspeaker box, enjoy pure digital music!. Specification Supply Voltage DC 12-24V Main Chip TPA3116 x 2 Channel Type 3 Channels(Left Channel, Right Channel, Subwoofer) Output Power 50W x 2 + 100W x 1 Subwoofer Output Match 4-8 ohm Audio Output Terminals Frequency Response Range 14-100KHz SNR 100dB Switching Frequency 1.2MHz PCB Board Size (LxWxH) mm 100 x 70 x 30 Weight 113g Shipping Weight 0.13 kg Shipping Dimensions 14 × 10 × 3 cm Package includes: 1 x TPA3116D2 50Wx2+100W Original IC 2.1 Channel Digital Subwoofer Amplifier Board 12V-24V
XH-M139 50Wx2+100W 2.1 Channel Digital Subwoofer Amplifier Board 12V-24V
[Amplifier Board] DC12-24V 2.1 Channel Digital Subwoofer Power Amplifier Board adopts two high-quality digital amplifier chips. Sound quality is very good, high efficiency and amplifying power. 50W x 2+100W 2.1 channels (left/right channel and subwoofer channel), high efficiency and low-heat. Users can adjust the volume by themselves easily. It is powered by DC 12-24V, wide input voltage. Features: Adopts two high-quality digital amplifier chips. Good sound quality, high efficient device and power amplifying feature. 50W x 2+100W 2.1 channels(left/right channel and subwoofer channel), high efficiency and low-heat. Powered by DC 12-24V, wide input voltage. User can adjust the volume by themselves easily. Applicable speaker impedance: 4-8 ohm. Just connect the power supply and loudspeaker box, enjoy pure digital music!. Specification Supply Voltage DC 12-24V Main Chip CS3835E0x 2 Channel Type 3 Channels(Left Channel, Right Channel, Subwoofer) Output Power 50W x 2 + 100W x 1 Subwoofer Output Match 4-8 ohm Audio Output Terminals Frequency Response Range 14-100KHz SNR 100dB Switching Frequency 1.2MHz PCB Board Size (LxWxH) mm 100 x 70 x 30 Weight 113g Shipping Weight 0.13 kg Shipping Dimensions 14 × 10 × 3 cm Package includes: 1 x DC12-24V 2.1 Channel Digital Subwoofer Power Amplifier Board
100K Ohm Linear Taper 16mm Rotary Potentiometer Elcon
[Potentiometer] Elcon B100K 100KΩ 16mm Rotary Potentiometer – 3 Pin D-Type Shaft The Elcon B100K 100KΩ Rotary Potentiometer is a compact 3-pin linear taper potentiometer designed for adjusting voltage, resistance, signal levels, brightness, motor speed, and other electrical parameters in electronic circuits. It has a total resistance of 100KΩ, with the resistance distributed linearly across the rotation of the shaft. The potentiometer can be used as a variable resistor or as a variable voltage divider. The two outer pins provide the full resistance value, while the center pin acts as the wiper and provides an adjustable resistance or voltage depending on the circuit connection. Its D-type shaft provides a secure grip for a compatible knob, while the included nut allows the potentiometer to be securely fixed to a panel or enclosure. The compact 16mm body makes it suitable for PCB and general-purpose electronic applications. ⭐ Key Features 100KΩ total resistance B100K linear taper 3-pin configuration D-type shaft Compact 16mm potentiometer Includes fixing nut Suitable for PCB mounting Can be used as a variable resistor Can be used as a variable voltage divider Suitable for tone and electronic control applications Breadboard compatible according to the supplied specifications 📋 Technical Specifications Product Type: Rotary Potentiometer Brand: Elcon Potentiometer Value: B100K / 100KΩ Taper: Linear Number of Pins: 3 Shaft Type: D-Type Shaft Diameter: 4mm Shaft Length: 8–10mm Pins Pitch: 4.4mm Dimensions: 25mm × 16mm × 16mm Nut Inner Diameter: 6mm Nut Outer Diameter: 10mm Mounting: PCB / Panel Mount Breadboard Compatible: Yes 🔌 Pin Function Outer Pin 1: Resistive track terminal Center Pin: Wiper / Variable output Outer Pin 3: Resistive track terminal The resistance between the two outer pins remains approximately 100KΩ, while the resistance between the center pin and either outer pin changes as the shaft is rotated. 🔧 Applications Tone Control Audio Circuits Signal Level Adjustment LED Brightness Control Motor Speed Control Voltage Adjustment Variable Resistor Applications Arduino Projects DIY Electronics Projects PCB Prototyping General Electronic Control Circuits 🛠️ How It Works When used as a potentiometer, the center pin acts as the adjustable wiper and provides a variable output across the rotation range. When used as a variable resistor, the wiper can be connected with one of the outer terminals to obtain an adjustable resistance. 📦 Package Includes 1 × Elcon B100K 100KΩ 3-Pin Rotary Potentiometer 1 × Fixing Nut ⚠️ Note Product images are for illustrative purposes only and may differ slightly from the actual product. The supplied specifications state a shaft length of 8–10mm; please verify the exact dimensions against the actual product batch before installation.
100K 16mm Linear Taper 6-Pin Dual Gang Rotary Potentiometer
[Potentiometer] The 100K 16mm Linear Taper Dual Gang Rotary Potentiometer is a precision variable resistor designed for accurate voltage and signal adjustment in audio, electronic, and industrial applications. Its dual-gang construction enables two separate circuits to be controlled simultaneously using a single rotating shaft, making it ideal for stereo volume control and dual-channel signal adjustment. Manufactured with high-quality resistive elements and durable metal components, the potentiometer delivers smooth rotation, low noise operation, excellent linearity, and long mechanical life. The 16mm body size provides a compact solution suitable for PCB mounting in amplifiers, mixers, DIY audio systems, control panels, and electronic equipment. The 100KΩ linear taper provides uniform resistance variation throughout the rotation angle, making it suitable for voltage dividers, signal attenuation, and control circuits where linear response is required. With a standard knurled shaft and 6 solder terminals, this potentiometer is easy to install and compatible with a wide variety of control knobs and electronic projects. 🔹 Key Features Dual gang rotary potentiometer 100KΩ linear taper resistance Smooth and precise rotation 16mm compact body 6-pin solder terminal design Low noise operation Long mechanical life Durable metal shaft Easy PCB mounting Suitable for stereo audio control 🔹 Technical Specifications Product Type: Dual Gang Rotary Potentiometer Resistance Value: 100KΩ Taper Type: Linear (B100K) Number of Gangs: Dual Number of Pins: 6 Body Diameter: 16mm Shaft Type: Knurled Metal Shaft Shaft Diameter: 6mm Shaft Length: Approx. 15mm Rotation Angle: Approx. 300° Mounting Type: PCB Through Hole Terminal Type: Solder Pins Power Rating: 0.125W (Typical) Resistance Tolerance: ±20% Operating Temperature: -10°C to +70°C 🔹 Applications Suitable for: Audio amplifiers Stereo volume control Tone control circuits Audio mixers Power amplifiers DIY electronics Signal level adjustment Voltage divider circuits Instrumentation equipment Electronic control panels 🔹 Package Includes 1 × 100K 16mm Linear Taper 6-Pin Dual Gang Rotary Potentiometer
